Our CS-series of carton sealers are operator fed and designed for heavy duty applications. These machines are reliable, cost-effective and durable providing savings to your production process. More importantly, these machines provide a professional looking seal.
The operator simply folds flaps of the corrugated carton and feeds it into the machine. Our carton sealer will apply a single tape strip to both the top & bottom of the case simultaneously. The carton sealer can easily be adjusted in only seconds to process a different size carton.
FEATURES
Adjustable table height
Heavy duty frame
Optional stainless steel frame
The most important variables to think about are: automation, package variety, and package size. We have also created a survey (download here) - Just email your completed survey to us and we will help you come up with the best carton sealer for your applications. Please contact us.
*Denotes special order unit. Lead time will vary.
| CS-6050 | CS-5050AC | CS-5050B | MSD | MS20 | MTD | |
|---|---|---|---|---|---|---|
| Value Unit Includes Casters Infeed/Exit Conveyors | Value Unit Includes Casters Infeed/Exit Conveyors | Value Unit Includes Casters Infeed/Exit Conveyors | Uniform Carton | Uniform Carton | Uniform Carton | |
| Carton Type | Taller | Narrow | Heavier | Low Profile, Smaller, Lightweight | Bottom Sealing Only | Tall Unstable Cartons |
| Min Width | 6.3" | 4.7" | 5.1" | 4.25" | 4.25" | 6.5" |
| Max Width | 19.7" | 19.6" | 19.7" | 20" | 20" | 20" |
| Min Height | 5.9" | 4.7" | 3.9" | 3.5" | N/A | 3.5" |
| Max Height | 23.6" | 19.6" | 19.7" | 20.5" | N/A | 20.5" |
| Max Weight | 55 | 66 | 88 | 65 | 65 | 65 |
| More Info | More Info | More Info | More Info | More Info | More Info |
