Table Top Tube Sealer

UHSS-Series | SKU: UHSS-8-SC8

Seal up to 3,500 tubes per day!  Ideal for laboratories, research facilities, R&D, and quality control groups.  Unit is economical, safe and very easy to use.  The tube sealers can be used on all polyethylene, and laminated tubes.  Sealers are equipped with a stainless steel shelf with height gauges to allow for easy changeover of various height tubes.  Included is a custom tray made for your tubes (sample tube required for fabrication).  Remember: When you order, please also send a sample tube if you want a custom tray fabricated for your tube.

FEATURES:

  • Seals up to 3 tubes at a time of 1-3/8" diameter, varies tube by tube

  • Easy to adjust with superior timing control (increments of 10th of a second)

  • Double force on seal bar

  • Easy maintenance resulting in lower downtime

  • Quieter operation and no metal shavings

  • Accommodates different tube heights and widths (max diameter 2" OD, 8.5" height)

  • Even pressure across seal length

  • Includes self-contained compressor

  • Lead Time:  3-5 business days

SPECIFICATIONS:

  • 8" seal length

  • Dual digital timer

  • Dual cylinder

  • Clevis pin

  • Delrin bushing

  • 1/4" wide single seal element (dual option available for better seal quality)

  • Only 0.0015 seal jaw deflection

  • Adjustable heating and cooling times

  • Exhaust port

  • Air in port

  • Detachable power cord

  • Made and designed in the USA

  • Tube tray custom made to your tubes (sample tube required for fabrication)

  • Manufacturer's kit includes:  (1) heating element, (2) Zone PTFE over element, (1) fuse

Made In the USA.jpg


Specifications:

Header 1Header 2
Seal Length8"
Seal Width1/4" (6MM)
Electrical115V / 10amps
Air Consumption60psi
Dimensions13" x 15" x 15"
Weight (lbs)45


Additional Options:

Spare Parts Kits:

Spare Parts Kit includes:  (1) Heating Element, (1) PTFE Insulator (under element), (2) PTFE Zone (over element) - dual kits include 2x.

Repair Kits include:  (1) Heating Element, (1) PTFE Insulator 11.5" (under silicone rubber), (2) PTFE Insulator 8" (under element), (2) PTFE Zone (over element),  (1) Silicone Rubber - dual kits include 2x
