Combo: L-Bar w/ Shrink Tunnel

Model No. LST-1616

The LST-1616 is designed for easy and quick shrink wrap packaging. Users can produce products that have a factory fresh clean look and feel. The sealer/tunnel combo creates packages that are free from dust, moisture and fingerprints.

This unique All-In-One L-Bar Sealer and Shrink Chamber is compact and quite the space saver. The shrink tunnel is located underneath the L-bar sealer ensuring a small footprint.

The sealer cuts and seals quick, sharp, and clean. One step cuts and seals film up to 15.7”. Sealing time is controlled by an electric timer. Once seal time is complete, operator places the product underneath in the shrink tunnel to complete shrink wrapping process.

FEATURES

  • Ideal for quick and easy shrink film packaging

  • Compact size – shrink tunnel below L-Bar sealer

  • Max seal width: 15.7”

  • Sits on casters – easy to move around

  • 220V – Customer provides own plug

  • Units ships via LTL freight only.  Call for freight rates

Specifications:

x
Power Supply220V / 1PH / 20Amps
Watts4500W
Seal Dimensions15.7"W x 15.7"L
Machine Dimensions44"L x 28"W x 44"H
Max Film Width16"
Max Package Height6"
Production Rate6-8PPM
Weight (lbs)330
